Description
The Analog Input Module provides fifteen analog inputs to the Multi-Function Controller or Processor for process field equipment and Bailey Smart Transmitters. It performs analog to digital (A/D) conversions on each input channel and can communicate to the Smart Transmitters for changing operating parameters and calibrating transmitter outputs. The IMFEC12 module is a 15 channel analog input module that allows 4-20 mA and 1-5 V analog inputs. This module can replace the IMFBS01 and the IMASI02 when they are used to for 1-5 V or 4-20 mA. The IMFEC11/12 can utilize the NTAI05, NIAI04, and the NTFB01 termination units. This module conforms to CE Mark.
